Place of Origin:
Qingdao
Brand Name:
Greef
Certification:
CE
Model Number:
GDG
An axial flux ironless core generator is a type of generator that has a unique design of an axial flux and an ironless core. The generator is used to generate electricity through the utilization of axial magnetic flux, all while avoiding iron core losses and hysteresis losses that are common in conventional generators.
The axial flux ironless core generator is typically made up of three main components: permanent magnets, coils, and casing. The permanent magnets are responsible for generating the magnetic field that is required for the generator to produce electricity. The coils are responsible for converting the energy in the magnetic field into electrical energy. Lastly, the casing provides protection to the internal structure of the generator and offers a sturdy support.
The operation of the axial flux coreless generator is based on the principle of electromagnetic induction. When the magnetic field produced by a permanent magnet moves in relation to a conductor that is situated in a coil, an emf is induced in the conductor. This emf is then further converted into electrical energy, which provides power to external devices.
Overall, the axial flux ironless core generator is a unique type of generator that provides an efficient and effective way of generating electricity.
| Model | GDG |
| Rated Power | 0.05KW-10KW |
| Option Rated Voltage | 24V-440Vac |
| Efficiency | >85% |
| Wending Method | Y |
| Insulating Resistance | 100Mohm Min(500V DC) |
| Phase Type | 3 Phase |
| Structure | Outer rotor |
| Stator | Coreless wire coil |
| Rotor | Rare Earth Permanent Magnet |
| Generator shell material | Aluminum alloy |
| Shaft material | Carbon steel |
| Bearing | NSK Deep groove ball bearing |
They are always being used in vertical axis wind turbine, and other generator system which requests very low start torque and low RPM.
Axial flux coreless generators have shown great potential in wind power generation, especially in megawatt-class wind turbines. These generators can significantly increase the output density, thus improving the efficiency of wind power generation. The absence of an iron core reduces iron losses and hysteresis losses, making the generator more efficient.
Axial flux coreless generators are not only used in wind power generation, but also in a wide range of renewable energy applications such as solar power generation systems. Their efficient energy conversion capability and reliable operation make them ideal for renewable energy generation systems.
The axial flux coreless generator can be used in various industrial applications that demand efficient, lightweight, and reliable power supply. For instance, it can be used as a backup or auxiliary power source to provide stable power support to industrial equipment.
With the flexible structure of the axial flux ironless core generator, it can be tailored to meet the specific needs of customers. For example, generator power, speed, and output voltage parameters can be adjusted to meet the requirements of different application scenarios.
At Greef, we understand that every project is unique. That's why we offer a range of product customization services to meet your specific needs. Whether you need a different output voltage, a different mounting configuration, or any other customization, we can help.
All of our products are manufactured in Qingdao and come with CE certification. Our minimum order quantity is just 1 set, and our prices are negotiable. We pack our generators with foam and plywooden cases to ensure safe delivery, and our delivery time is only 25 working days.
We accept payment via T/T, Western Union, MoneyGram, and L/C, and we have a supply ability to meet your needs. Our generators are available in both outer rotor and inner rotor configurations, and are designed as 3 Phase AC Permanent Magnet generators with an IP 54 protection grade.
Product Packaging:
The Coreless Permanent Magnet Generator will be packaged securely in a cardboard box with foam padding to prevent any damage during transit. The product will also be wrapped in bubble wrap for additional protection.
Shipping:
The product will be shipped via a reliable courier service with tracking information provided to the customer upon dispatch. Shipping times may vary depending on the customer's location, but we strive to ensure prompt delivery within the specified timeframe.
